3BC587LB, Campana decorativa de pared inclinada, BALAY

FICHA TÉCNICA

PRODUCTO

• FAMILY
• CODE 3BC587LB
• USP_MAIN Campana de pared inclinada de la Serie Cristal: libertad de movimientos en la zona de cocción y elegancia en toda la cocina.
• ART_NUM 3BC587LB
• COL_BODY_HOODS Blanco
• MAT_BODY Cristal, Esmaltada
• COL_CHIMNEY noData
• MAT_CHIMNEY noData
• TYPOLOGY noData
• CONTROL_TYPE Electrónica
• CONSTR_TYPE Integrable
• INST_TYPE Montaje en pared
• CONTROL_SETTING Por app
• FRONT_PANEL_OPTIONS N/A
• MOTOR_LOCATION Motor integrado en el cuerpo de la campana
• OPERATING_MODE Convertible
• CONNECTION 200
• CURRENT 10
• VOLTAGE 220-240
• FREQUENCY 50; 60
• CERTIFICATES
• CORD_LGTH 130
• PLUG_TYPE Schuko con conexión a tierra
• HEIGHT_WITHOUT_CHIMNEY 450
• HEIGHT 450
• WIDTH 790
• DEPTH 433
• HEIGHT_PACKED 770
• WIDTH_PACKED 730
• DEPTH_PACKED 1220
• HEIGHT_NICHE_SIZE_MIN noData
• HEIGHT_NICHE_SIZE_MAX noData
• WIDTH_NICHE_SIZE_MIN noData
• WIDTH_NICHE_SIZE_MAX noData
• DEPTH_NICHE_SIZE noData
• WEIGHT_NET 24.5
• WEIGHT_GROSS 36.1
• AIR_EXHAUST_AVAILABLE Si
• CHIMNEY_HEIGHT_EXHAUST_MAX 663
• CHIMNEY_HEIGHT_EXHAUST_MIN 420
• CHIMNEY_HEIGHT_RECIRC_MAX 750
• CHIMNEY_HEIGHT_RECIRC_MIN 457
• ASSEMBLY_LEVEL
• ENERGY_LABEL_APPLICABLE Si
• ENERGY_CLASS_2010 A+
• ENERGY_ANNUAL 35.5
• FLUID_DYNAMIC_EFFICIENCY 39.7
• FLUID_DYNAMIC_CLASS A
• LIGHT_EFFICIENCY 58.6
• LIGHT_CLASS A
• GREASE_FILTER_EFFICIENCY 81.4
• GREASE_FILTER_CLASS C
• AIR_FLOW_MAX 432
• AIR_FLOW_MIN 223
• AIR_FLOW_BOOST 915.0
• SOUND_POWER_MAX 51
• SOUND_POWER_MIN 35
• SOUND_POWER_BOOST 68
• POWER_CONS_STANDBY 0.33
• POWER_OFF_MODE_2010 noData
• NOISE 51
• NOISE_BOOST 68
• ECO_LABEL
• MANUAL_CONTROL_DEVICES touch control
• AUTOMATIC_CONTROL_DEVICES noData
• REMOTE_CONTROL No
• MOTOR_NUMBER 1
• TOTAL_POWER_MOTORS 190
• MAX_OUTPUT_EXTRACTION 432
• BOOST_OUTPUT_EXTRACTION 915
• MAX_OUTPUT_RECIRCULATION 438
• BOOST_OUTPUT_RECIRCULATION 886
• LIGHT_CNT_TYPE Continuo
• LIGHTS_NUMBER 2
• LAMPS_TOTAL_POWER noData
• LUMINANCE_TOTAL 422
• GREASE_FILTER_MAT Acero inoxidable lavable
• AIR_OUTLET_DIAMETER 150
• GREASE_FILTER_TYPE noData
• NO_RETURN_FLAP Si
• ODOUR_FILTER No
• ACCESSORIES_INCL noData
• ACCESSORIES
• SPEED_SETTINGS noData
• LAMPS_TYPE N/A
• PRODUCT_IMAGE https://media3.bsh-group.com/Product_Shots/3000x3000/22142598_3BC587LB_STP_def.jpg
• MEASURE_IMAGE
• PANEL_IMAGE
• ADD_IMAGE1_ID https://media3.bsh-group.com/Product_Shots/3000x3000/23164890_3BC587LB_PGA1_def.jpg
• ADD_IMAGE2_ID https://media3.bsh-group.com/Product_Shots/3000x3000/23353331_3BC587LB_PGA2_def.jpg
• ADD_IMAGE3_ID https://media3.bsh-group.com/Product_Shots/3000x3000/23166128_3BC587LB_PGA3_def.jpg
• ADD_IMAGE4_ID https://media3.bsh-group.com/Product_Shots/3000x3000/23233080_3BC587LB_PGA4_def.jpg
• ADD_IMAGE5_ID https://media3.bsh-group.com/Product_Shots/3000x3000/23377389_3BC587LB_PGA5_def.jpg
• ADD_IMAGE6_ID
• ADD_IMAGE7_ID
• ENERGY_LABEL
• PRODUCT_FICHE
• USP_1 Consigue más espacio libre con la disposición inclinada de la campana.
• USP_2 Sistema de insonorización de tu campana para una cocina libre de ruido.
• USP_3 Motor de alta eficiencia, que consume menos y con 10 años de garantía.
• USP_4 Filtros de aspiración perimetral: estéticos, eficaces reteniendo grasas y además… lavables en lavavajillas.
• USP_5 Adaptable a cada espacio y cocina. Posibilidad de instalación en recirculación.
